Front brake discs Rotinger Tuning series 2798, (2psc)

Dimensions:

Diameter: 280mm

Total Height: 42mm

Thickness New/ Min: 25 / 22mm

Number of bolt holes: 7

Type: VENTED

Specification: --

OEM: 569060;569066;90539466;9117678;93197592;

Cross refference:

ATE: 24012501311 , 24032501311

BOSH: 0986478883

Brembo: 09762910 , 09762911/p>

Jurid: 562070J

Textar: 92091900

TRW: DF4048

Delphi: BG3405

Zimmermann: 430148300

Application:

OPEL CORSA C (F08, F68) 1.7 CDTI, 74Kw / 100 HP

OPEL ASTRA H TwinTop 1.8, 103Kw / 140 HP

OPEL MERIVA 1.7 DTI, 55Kw / 75 HP

OPEL ZAFIRA A (F75_) 2.2 DTI 16V, 86Kw / 117 HP

OPEL MERIVA B 1.7 CDTI, 96Kw / 131 HP

OPEL ASTRA H Saloon 1.8, 103Kw / 140 HP

OPEL ASTRA G Saloon (F69_) 1.8 16V, 85Kw / 116 HP

OPEL ASTRA H Estate 1.6, 85Kw / 116 HP

OPEL ASTRA H GTC 1.7 CDTI, 81Kw / 110 HP

OPEL ASTRA H GTC 1.7 CDTI, 92Kw / 125 HP

OPEL ASTRA H GTC 1.2, 59Kw / 80 HP

OPEL ASTRA G Estate (F35_) 2.2 16V, 108Kw / 147 HP

OPEL ASTRA H Van 1.3 CDTI, 66Kw / 90 HP

OPEL COMBO Tour 1.7 CDTI 16V, 74Kw / 101 HP

OPEL ASTRA H 1.4, 55Kw / 75 HP

OPEL ASTRA H 1.2, 59Kw / 80 HP

OPEL ZAFIRA A (F75_) 1.8 16V, 85Kw / 116 HP

OPEL ZAFIRA A (F75_) 2.2 16V, 108Kw / 147 HP

OPEL ASTRA G Coupe (F07_) 2.2 DTI, 92Kw / 125 HP

OPEL ASTRA H Saloon 1.7 CDTI, 92Kw / 125 HP

OPEL ASTRA G Estate (F35_) 1.8 16V, 92Kw / 125 HP

OPEL ASTRA H Estate 1.7 CDTI, 74Kw / 101 HP

OPEL ASTRA G Saloon (F69_) 2.2 16V, 108Kw / 147 HP

OPEL ASTRA G Estate (F35_) 2.0 16V, 100Kw / 136 HP

OPEL ASTRA G Estate (F35_) 2.2 DTI, 92Kw / 125 HP

OPEL ASTRA H GTC 1.4, 55Kw / 75 HP

OPEL ASTRA H GTC 1.6, 77Kw / 105 HP

OPEL ASTRA H GTC 1.7 CDTI, 59Kw / 80 HP

OPEL ASTRA H Estate 1.6 LPG, 85Kw / 116 HP

OPEL ASTRA Sports Tourer (J) 1.6 LPG, 84Kw / 114 HP

OPEL ASTRA H Estate 1.4, 66Kw / 90 HP

OPEL ASTRA H 1.8, 92Kw / 125 HP

OPEL ASTRA G Hatchback (F48_, F08_) 2.2 DTI, 92Kw / 125 HP

OPEL ASTRA H TwinTop 1.6, 77Kw / 105 HP

OPEL ASTRA H Estate 1.6, 77Kw / 105 HP

OPEL ASTRA G Estate (F35_) 2.0 DI, 60Kw / 82 HP

OPEL ASTRA H Saloon 1.6, 85Kw / 116 HP

OPEL ASTRA H Van 1.7 CDTI, 81Kw / 110 HP

OPEL ASTRA G Hatchback (F48_, F08_) 1.8 16V, 92Kw / 125 HP

OPEL ASTRA G Convertible 2.2 16V, 108Kw / 147 HP

OPEL ZAFIRA A (F75_) 1.8 16V, 92Kw / 125 HP

OPEL ASTRA G Estate (F35_) 2.0 DTI 16V, 74Kw / 101 HP

OPEL ASTRA H GTC 1.6, 85Kw / 116 HP

OPEL ASTRA H Van 1.7 CDTI, 74Kw / 101 HP

OPEL ASTRA G Saloon (F69_) 2.2 DTI, 92Kw / 125 HP

OPEL MERIVA B 1.4, 74Kw / 100 HP

OPEL ASTRA G Box (F70) 2.0 DI, 60Kw / 82 HP

OPEL ASTRA G Estate (F35_) 1.7 CDTI, 59Kw / 80 HP

OPEL ASTRA H Estate 1.4, 55Kw / 75 HP

OPEL ASTRA H 1.4 LPG, 66Kw / 90 HP

OPEL MERIVA 1.7 CDTI, 92Kw / 125 HP

OPEL ASTRA G Convertible 2.2 DTI, 92Kw / 125 HP

OPEL MERIVA 1.4 16V Twinport, 66Kw / 90 HP

OPEL ASTRA G Hatchback (F48_, F08_) 2.0 16V, 100Kw / 136 HP

OPEL ZAFIRA B (A05) 1.6, 77Kw / 105 HP

OPEL ZAFIRA A (F75_) 2.2 DTI 16V, 92Kw / 125 HP

OPEL ASTRA H 1.3 CDTI, 66Kw / 90 HP

OPEL ASTRA H GTC 1.3 CDTI, 66Kw / 90 HP

OPEL ASTRA G Saloon (F69_) 2.0 DI, 60Kw / 82 HP

OPEL ASTRA G Hatchback (F48_, F08_) 2.2 16V, 108Kw / 147 HP

OPEL ASTRA G Estate (F35_) 2.2 DTI, 86Kw / 117 HP

OPEL ASTRA H 1.6, 85Kw / 116 HP

OPEL ASTRA H Saloon 1.3 CDTi, 66Kw / 90 HP

OPEL ASTRA H 1.7 CDTI, 74Kw / 100 HP

OPEL ASTRA H GTC 1.8, 92Kw / 125 HP

OPEL MERIVA B 1.3 CDTI, 55Kw / 75 HP

OPEL MERIVA 1.3 CDTI, 55Kw / 75 HP

OPEL ASTRA H TwinTop 1.8, 92Kw / 125 HP

OPEL ASTRA H GTC 1.4, 66Kw / 90 HP

OPEL ASTRA H 1.7 CDTI, 59Kw / 80 HP

OPEL ASTRA G Saloon (F69_) 2.0 16V, 100Kw / 136 HP

OPEL ASTRA H Saloon 1.7 CDTi, 81Kw / 110 HP

OPEL ASTRA G Coupe (F07_) 1.8 16V, 92Kw / 125 HP

OPEL ZAFIRA B (A05) 1.8, 103Kw / 140 HP

OPEL ASTRA H Estate 1.7 CDTI, 81Kw / 110 HP

OPEL MERIVA 1.6 16V, 74Kw / 100 HP

OPEL MERIVA 1.6, 77Kw / 105 HP

OPEL ASTRA G Estate (F35_) 1.8 16V, 85Kw / 116 HP

OPEL ASTRA G Estate (F35_) 1.6 CNG, 71Kw / 97 HP

OPEL ASTRA H TwinTop 1.6, 85Kw / 116 HP

OPEL ZAFIRA A (F75_) 1.6 CNG, 71Kw / 97 HP

OPEL ASTRA H 1.7 CDTI, 92Kw / 125 HP

OPEL ASTRA H Estate 1.7 CDTI, 92Kw / 125 HP

OPEL ASTRA G Hatchback (F48_, F08_) 2.0 DI, 60Kw / 82 HP

OPEL ASTRA H Van 1.7 CDTI, 92Kw / 125 HP

OPEL ASTRA G Hatchback (F48_, F08_) 1.8 16V, 85Kw / 116 HP

OPEL ASTRA H 1.7 CDTI, 81Kw / 110 HP

OPEL ASTRA H Estate 1.8, 103Kw / 140 HP

OPEL ASTRA G Convertible 1.8 16V, 92Kw / 125 HP

OPEL ASTRA H 1.6, 77Kw / 105 HP

OPEL ZAFIRA B (A05) 1.6, 85Kw / 115 HP

OPEL COMBO Box Body / Estate 1.7 CDTI 16V, 74Kw / 101 HP

OPEL ASTRA H Saloon 1.7 CDTi, 74Kw / 101 HP

OPEL MERIVA B 1.3 CDTI, 70Kw / 95 HP

OPEL MERIVA B 1.4, 88Kw / 120 HP

OPEL ZAFIRA A (F75_) 1.6 16V, 74Kw / 101 HP

OPEL MERIVA 1.8, 92Kw / 125 HP

OPEL MERIVA B 1.4 LPG, 88Kw / 120 HP

OPEL ASTRA G Coupe (F07_) 1.8 16V, 85Kw / 116 HP

OPEL ASTRA G Saloon (F69_) 1.8 16V, 92Kw / 125 HP

OPEL MERIVA 1.7 CDTI, 74Kw / 100 HP

OPEL MERIVA 1.4 16V Twinport LPG, 66Kw / 90 HP

OPEL ASTRA G Hatchback (F48_, F08_) 2.2 DTI, 86Kw / 117 HP

OPEL ZAFIRA A (F75_) 2.0 DI 16V, 60Kw / 82 HP

OPEL ZAFIRA B (A05) 1.7 CDTI, 92Kw / 125 HP

OPEL CORSA C Box (F08, W5L) 1.7 CDTi, 74Kw / 101 HP

OPEL MERIVA B 1.7 CDTI, 74Kw / 100 HP

OPEL ASTRA G Coupe (F07_) 2.2 16V, 108Kw / 147 HP

OPEL ASTRA G Saloon (F69_) 2.2 DTI, 86Kw / 117 HP

OPEL ZAFIRA B Van 1.8, 103Kw / 140 HP

OPEL ASTRA H 1.4, 66Kw / 90 HP

OPEL ASTRA H GTC 1.8, 103Kw / 140 HP

OPEL ASTRA H Estate 1.8, 92Kw / 125 HP

OPEL ASTRA G Hatchback (F48_, F08_) 2.0 DTI 16V, 74Kw / 101 HP

OPEL MERIVA B 1.7 CDTI, 81Kw / 110 HP

OPEL ASTRA H 1.8, 103Kw / 140 HP

OPEL ZAFIRA A (F75_) 2.0 DTI 16V, 74Kw / 101 HP

OPEL ASTRA H Estate 1.4 LPG, 66Kw / 90 HP

OPEL ZAFIRA C (P12) 1.8 LPG, 101Kw / 137 HP

OPEL MERIVA 1.3 CDTI, 51Kw / 69 HP

OPEL ASTRA H Estate 1.7 CDTI, 59Kw / 80 HP

OPEL ZAFIRA A (F75_) 2.0 DTI, 63Kw / 86 HP

OPEL ASTRA G Saloon (F69_) 2.0 DTI 16V, 74Kw / 101 HP

OPEL ASTRA H GTC 1.7 CDTi, 74Kw / 101 HP

OPEL ASTRA H Estate 1.3 CDTI, 66Kw / 90 HP

Rotinger brake discs are the result of advanced cutting technology. High quality and attractive design attracts the attention of all tuning enthusiasts. Efficient design ensures reduced braking distance, braking gas emissions and improves cooling properties. Rotinger offers a wide range of brake discs for most cars. Depending on the personal choice, the customer can choose from up to five possible types of brake discs. Simple (without drilling and grooving), Slotted, Drilled and combinations thereof. Attractive slots were designed in a carefully thoughtful way. Their design ensures efficient brake pads cleaning and less turbulence of the braking dust. The original Rotinger brake disc is the result of years of research and under no circumstances can it be copied to other brake discs. Each new pattern is tested under extreme conditions in which its quality and operational safety are confirmed. Offering 1400 kinds of brake discs for more than 95% of the cars on the market. The entire manufacturing process meets all safety standards and quality standards. ISO / TS 16949: 2009, ISO 9001: 2008, ISO 14001: 2004 certificates confirm the quality of the products and the Rotinger process. Rotinger offers Tuning series and High performance brake discs. Both types can be ordered in Graphite Line design and basic or drilled design. The

Tuning series offers excellent anti-corrosion protection combined with an attractive design that will appeal to every fan of sports brake discs. Effective styling significantly reduces the braking distance and greatly helps to drain gases when braking. Ventilation areas ensure optimal cooling of the brake disc.

Rotinger High Performance, brake discs enriched with carbon compounds and innovative anti-corrosion protection. Increased carbon content ensures better thermal distribution, lower temperature changes and resistance to deformation of the disc under heavy braking. Thermal strain is one of the most common problems of today's vehicles, which leads to unpleasant vibrations during braking. Unique design combined with a carbon structure ensures high braking performance under all conditions
