CYBUL BMW E30 angle lock kit, 5x120 E36 knuckles conversion

The maximum turning angle exceeds 70 degrees, and it’s adjustable. The steering wheel “comes back” to its position as it’s supposed to.

Nov izdelek

Dobavljivo po naročilu

Najkasneje na vašem domu: 7. 1.

1.074,80 € z DDV

CYBUL-LK-003

Povpraševanje o izdelku

Povpraševanje o izdelku

CYBUL BMW E30 angle lock kit, 5x120 E36 knuckles conversion

CYBUL BMW E30 angle lock kit, 5x120 E36 knuckles conversion

The maximum turning angle exceeds 70 degrees, and it’s adjustable. The steering wheel “comes back” to its position as it’s supposed to.

Vprašanje o tem izdelku pošljite lastniku trgovine.

* Obvezna polja

  ali  Prekliči

Notify me

Notify me about the stock

CYBUL BMW E30 angle lock kit, 5x120 E36 knuckles conversion

CYBUL BMW E30 angle lock kit, 5x120 E36 knuckles conversion

To be informed about product update via email, fill out the form.

* Required

  or  Cancel

The maximum turning angle exceeds 70 degrees, and it’s adjustable. The steering wheel “comes back” to its position as it’s supposed to.

Cybul BMW E30 angle lock kit was developed after first succesfull tests of E36 anlgle lock kit. It was 3D CAD designed and tested on the track. Our engineers were in close contact with test drivers. Each test session resulted in key suggestions about required improvements in the handling. The finally available product to the public takes the handling of E30 to a whole new level, providing over 70 degrees of maximum turning angle.

Main benefits:

  • Correct steering wheel behavior – it comes back easily during transitions, does not wobble on the full lock
  • Over 70 degrees of maximum lock angle
  • Changed suspension and steering kinematics – reduced bump steer on turned wheels, corrected roll center, increased camber angle, deleted Ackerman angle, corrected caster angle, improved steering responce
  • Maximum angle lock can be adjusted steplessly. 2 adjustable limiters on each control arm allow you to stop the wheel from rubbing the bodyshell
  • Camber plates allow adjustment of caster angle
  • Camber angle can be adjusted on the control arm
  • Allows converitng to E36 knuckles (bigger brakes, more rims available)


Key features:

  • Made of high strength steel
  • All the parts required for installation are included in the kit
  • Motorsport rod ends are used for longevity – 3-piece, PTFE lined with 4130 chromoly body
  • Rubber covers for rod ends provide water and dust protection
  • Pivots housings are welded at a correct angle which guarantees pivots longevity
  • 100% bolt-on solution
  • 3D cad designed
  • 100% made in the EU

Includes:

  • 2 (pair) control arms
  • 2 (pair) rod ends for control arms
  • 4 (2 pairs) rubber covers for rod ends
  • 2 (pair) pivots
  • 2 (pair) 90 ShA polyurethane bushings for control arms
  • 2 (pair) camber plates
  • 2 (pair) spherical bearing for camber plates with circlips
  • 2 (pair) steering rods
  • 2 (pair) rod ends for steering rods
  • 4 (two pairs) high angle misalignment bushings for steering rods rod ends
  • 2 (pair) knuckle adapters
  • 4 (two pairs) chromoly, heat-treated cone inserts for knuckles
  • Set of bolts and nuts
  • Printed installation manual
