Garrett 836028-5005S Supercore GT Series GT3071R

Garrett GT3071R supercore — a balanced core assembly (centre cartridge with compressor cover and back plate) for building or rebuilding GT turbochargers.

Garrett GT Series is the name that pioneered turbo technology and boosted drag racing and road racing teams to break hundreds of world records.

The GT Series lineup is offered in both journal and ball bearing options, and sizes ranging from GT2052 to GT3582.

The cast compressor wheels feature original GT Series aerodynamics and provide maximum durability and longevity.

Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations.

Specifications

• Frame: GT30
• Bearing: ball bearing
• Rotation: standard
• Compressor wheel: 53 mm inducer, 71 mm exducer, 0.5 A/R
• Turbine wheel: 60 mm inducer, 55 mm exducer, 84 trim
• Inlet flange: T04E
• Power: up to 480 HP
• Displacement: 2.5-3.5 L

Fits & compatible parts

• Compatible turbochargers: GT2052, GT3582

Features

• About Garrett GT Series Turbochargers
