Lock kit for NISSAN S13 - FULL KIT

The subject of the sale is a complete lock enlargement kit dedicated to the Nissan S13.

The set is based on complete crossovers milled from one block of material. The modular structure ensures trouble-free assembly and flexibility for individual applications. Locking pins ensure a secure fit. The use of 5x114.3 wheel hubs allows the use of a wider range of rims.

The track width will increase by 14cm and will therefore require widening.

The use of an 8J ET30 rim and 225/45/17 tires avoids cutting out the inner fenders.

Everything is milled on CNC machines, which gives a high quality finish and 100% matching of the elements to each other. The material from which the set was made is aluminum 7075, which demonstrates the strength of structural steels while maintaining a lower weight.

The swingarm is laser cut from structural steel and equipped with uniball joints with conical mounting sleeves.

In addition, the kit is equipped with high quality wishbone pins and complete steering rods.

Relocation of the upper mounting requires drilling an inspection hole in the socket for the shock absorber. Template included.

When assembling the set, nothing needs to be cut, welded or grinded. Everything is fitted plug & play, the operation is fully reversible, the car body remains intact except for the aforementioned hole.

The lock kit for NISSAN S13 consists of:

• LEFT front control arm - 1 piece
• RIGHT front control arm - 1 piece
• crossover body - 2 pieces
• shock absorber mounting - 2 pieces
• crossover adapter LEFT - 1 piece
• crossover adapter RIGHT - 1 piece
• hubs - 2 pieces
• plates of the upper fastening - 2 pieces
• washers of the upper fastening - 2 pieces
• baskets for a spherical bearing with a lid - 2 pieces
• reduction sleeves for the shock absorber - 4 pieces
• mounting bolts - 8x hubs, 4x adapters, 8x shock absorber mounts, 22x top mounts
• rocker pins - 2 pcs
• complete steering rods - 2 pcs
• relocators of steering rods with bolts M16x1 - 2 pcs.
• high quality uniballs with mounting sleeves - 4 pieces
• uniball sleeves - 8 pieces

We add assembly instructions to the set.

The kit requires the removal of the front stabilizer from the vehicle and is intended for use during closed drifting events on secure facilities!
