DBA 4000 series T3 DBA4908S (2 pcs)

Feature: T3 Slot – 48 precision CNC machined slots

Advantage: Tri-symmetrical curve slots dampen vibration harmonics or noise

Benefit: A quieter, responsive and smoother brake pedal feel

Advantage: Increased number of out-gassing exit points for brake pad friction gases to escape through

Benefit: Increases the consistency and effectiveness of every brake stop

Advantage: Universal slot design

Benefit: Eliminates the need for left and right discs

Feature: Kangaroo Paw – 144 diamond and tear drop pillar ventilation system

Advantage: Increased surface area resulting in greater heat dissipation

Benefit: Minimises brake fade and increases braking effectiveness

Advantage: Increased surface area resulting in greater heat dissipation

Benefit: Prolongs service life for both pads and rotors. Reduces mechanical damage and associated costs

Feature: XG150 High Carbon Alloyed Iron

Advantage: Increased thermal capacity allows handling constant extremes of heat

Benefit: Minimises warping and cracking; prolongs rotor service life

Feature: Thermal Stability Profiling (TSP)

Advantage: Special formulation responds to DBA’s TSP process

Benefit: Minimises warping and cracking; prolongs rotor service life

Feature: Thermographic Temperature Monitoring

Advantage: Heat paint markings change colour at specific temperature thresholds

Benefit: Offers the driver a clear indication of peak braking temperatures

Advantage: Permanent colour change when temperature thresholds are exceeded

Benefit: Allows monitoring of rotor fatigue and supports warranty claims

Feature: Paint protection on non-friction areas

Advantage: Reduces corrosion

Benefit: Prevents unsightly rust formation

Advantage: Enhances appearance

Benefit: Adds value to the product

Technical information:

Diameter [mm]: 297
Disc Vent: Kangaroo Paw
Number of Holes: 5
Inner Diameter [mm]: 68
Minimum Thickness [mm]: 16
Thickness [mm]: 18
Height [mm]: 63
Pitch Circle [mm]: 114.3
Stage: Stage 4
ECE R90 number: E11*90R02/06*60520*00

Suitable for:

Rear - NISSAN/300ZX GZ32/3.0 Not UK (1989-1994) Brake Pads: DB1220, Rear - NISSAN/300ZX GZ32/3.0 Not UK (1994-1998) Brake Pads: DB1220, Rear - NISSAN/300ZX Z32/3.0 Twin Turbo (1990-1994) Brake Pads: DB1220, Rear - NISSAN/Skyline (R32)/2.0 Turbo GTS (1989-1994) Brake Pads: DB1144, Rear - NISSAN/Skyline (R32)/2.0 Turbo GTS-T (1989-1994) Brake Pads: DB1220, Rear - NISSAN/Skyline (R32)/2.0 Turbo GTS-T (1991-1994) Brake Pads: DB1144, Rear - NISSAN/Skyline (R32)/2.6 Twin Turbo GT-R (1989-1995) Brake Pads: DB1220, Rear - NISSAN/Skyline (R33)/2.5 Turbo GTS-T (1993-1998) Brake Pads: DB1220, Rear - NISSAN/Skyline (R34)/2.5 Turbo GT-T (1998-2002) Brake Pads: DB1220,
