Garrett 938339-5001S Supercore G-Series II G42-1325C

Garrett G42-1325C supercore — a balanced core assembly (centre cartridge with compressor cover and back plate) for building or rebuilding G-Series II turbochargers.

The Garrett G42-1325C G-Series II Compact Supercore turbocharger delivers advanced performance in a more compact format, specifically designed for motorsport and high-output applications.

Specifications

• Frame: G42
• Bearing: ball bearing
• Rotation: standard
• Compressor wheel: 73 mm inducer, 91 mm exducer
• Turbine wheel: 82 mm inducer, 75 mm exducer, 84 trim
• Turbine wheel material: Inconel alloy
• Power: up to 1325 HP
• Displacement: 2.0-7.0 L

Fits & compatible parts

• Compatible turbochargers: G42-1325

Features

• Specifications
• Compressor Inducer: 73 mm
• Compressor Exducer: 91 mm
• Compressor Wheel Material: Forged Fully Machined
• Compressor A/R: 0.88
• Turbine Inducer: 82 mm
• Turbine Exducer: 75 mm
• Turbine Trim: 84
