Xtreme clutch

KGM18630-3E Xtreme Performance 184mm Rigid Ceramic Triplate Plate Clutch Kit Incl Flywheel & CSC

Xtreme Clutch delivers expertly engineered, high-performance clutch solutions for the street and track. Trusted by professional race teams worldwide, we provide the ultimate upgrade for your driving experience.

Nov izdelek

Razprodano

2.578,80 € z DDV

Žal izdelek začasno ni na voljo. Prosim izberite drugega.

Povpraševanje o izdelku

Povpraševanje o izdelku

KGM18630-3E Xtreme Performance 184mm Rigid Ceramic Triplate Plate Clutch Kit Incl Flywheel & CSC

KGM18630-3E Xtreme Performance 184mm Rigid Ceramic Triplate Plate Clutch Kit Incl Flywheel & CSC

Xtreme Clutch delivers expertly engineered, high-performance clutch solutions for the street and track. Trusted by professional race teams worldwide, we provide the ultimate upgrade for your driving experience.

Vprašanje o tem izdelku pošljite lastniku trgovine.

* Obvezna polja

  ali  Prekliči

Notify me

Notify me about the stock

KGM18630-3E Xtreme Performance 184mm Rigid Ceramic Triplate Plate Clutch Kit Incl Flywheel & CSC

KGM18630-3E Xtreme Performance 184mm Rigid Ceramic Triplate Plate Clutch Kit Incl Flywheel & CSC

To be informed about product update via email, fill out the form.

* Required

  or  Cancel

Za samodejne informacije o zalogah izdelkov,
kliknite na "Obvestite me, ko bo na voljo".

KGM18630-3E

9337467164220

Xtreme Clutch delivers expertly engineered, high-performance clutch solutions for the street and track. Trusted by professional race teams worldwide, we provide the ultimate upgrade for your driving experience.

-3E

The Xtreme 184mm Race Clutch is an economically priced solution for those wanting a strong Race clutch without having to compromise on quality. The Race Clutch is a lightweight design for when every second counts.

 Ø184mm Light Diaphragm (2.6mm)Ø184mm Heavy Diaphragm (2.8mm)
Clamping Force950kg1080kg
Torque Rating1600Nm1820Nm
Bearing Contact Diameter44-52mm44-52mm
Bearing Load (@ 48mm)210kg260kg
Release Travel Required5mm5mm
Assembly Mass (without flywheel)4.75kg4.75kg
Disc Set Static Mass1.2kg
Friction Thickness New2.6mm (0.103")2.6mm (0.103")
Friction Thickness Worn2.36mm (0.093")2.36mm (0.093")

Product Features:

  • Push type billet alloy cover
  • 4140 Chromoly pressure plate
  • Hardened steel wear posts
  • High and low ratio pressure plate options
  • Low inertia
  • Serviceable components
  • SFI certified design

Tech. Info:

Reference: KGM18630-3E

Weight: 18.33

Note:

Clutch Disc Diameter (mm): 184
Clutch Disc Spline Count: 26
Clutch Disc Spline Diameter (mm): 28.6
Torque (Nm): 1830
Flywheel Step: +2.5mm
Design: Triple Plate
Stage: Multiplate - track use only
Clamp Load: 900Kg
Recommended for: Motorsport
Ring Gear Tooth count:
Additional information:

184mm Triple Plate

Suitable for:

- Holden/H Series/5.7 i V8/2004.11-2005.12/5665 Petrol 260 kW 354 BHP (2004.11 - 2005.12)
Holden/H Series/VZ | 6.0i V8/2005.11-2006.06/L76 5967 Petrol 260 kW 354 BHP (2005.11 - 2006.06)
Holden/H Series/VE | 6.0i V8/2007.09-2010.09/L76 5967 Petrol 260 kW 354 BHP (2007.09 - 2010.09)
Holden/H Series/VZ | 6.0i V8 4x4/2005.11-2006.07/L76, LS2(364CUV8) 5967 Petrol 260 kW 354 BHP (2005.11 - 2006.07)
Holden/H Series/VZ | 6.0i V8/2005.11-2007.08/L76, LS2(364CUV8) 5967 Petrol 260 kW 354 BHP (2005.11 - 2007.08)
HSV/Senator/VZ | 6.0i V8/2004.10-2006.07/L76, LS2(364CUV8) 5967 Petrol 297 kW 404 BHP (2004.10 - 2006.07)
HSV/Clubsport/VZ | 6.0i V8/2004.10-2006.12/L76, LS2(364CUV8) 5967 Petrol 297 kW 404 BHP (2004.10 - 2006.12)
HSV/Maloo/VZ | 6.0i V8/2004.10-2007.09/L76, LS2(364CUV8) 5967 Petrol 297 kW 404 BHP (2004.10 - 2007.09)
HSV/GTO/VX, VZ | 6.0i V8/2004.10-2007.11/L76, LS2(364CUV8) 5967 Petrol 297 kW 404 BHP (2004.10 - 2007.11)
Chevrolet/Camaro/5.7/1998.07-2002.12/LS1 5665 Petrol 212 kW 288 BHP (1998.07 - 2002.12)
Holden/H Series/VT | 5.7i V8/1999.06-2000.08/LS1 5665 Petrol 220 kW 299 BHP (1999.06 - 2000.08)
Holden/H Series/VT | 5.7i V8/1999.06-2000.10/LS1 5665 Petrol 220 kW 299 BHP (1999.06 - 2000.10)
Holden/H Series/VX | 5.7i V8/2000.09-2002.09/LS1 5665 Petrol 225 kW 306 BHP (2000.09 - 2002.09)
Holden/H Series/VU | 5.7i V8/2000.12-2002.09/LS1 5665 Petrol 225 kW 306 BHP (2000.12 - 2002.09)
Holden/H Series/5.7 i V8/2001.12-2003.01/LS1 5665 Petrol 225 kW 306 BHP (2001.12 - 2003.01)
Holden/H Series/VY | 5.7i V8/2002.09-2003.08/LS1 5665 Petrol 225 kW 306 BHP (2002.09 - 2003.08)
Holden/H Series/VY | 5.7i V8/2003.09-2004.07/LS1 5665 Petrol 225 kW 306 BHP (2003.09 - 2004.07)
Holden/H Series/VY | 5.7i V8/2002.09-2004.08/LS1 5665 Petrol 235 kW 320 BHP (2002.09 - 2004.08)
Holden/H Series/5.7 i V8/2003.01-2003.08/LS1 5665 Petrol 235 kW 320 BHP (2003.01 - 2003.08)
Holden/H Series/5.7 i V8/2003.08-2004.07/LS1 5665 Petrol 235 kW 320 BHP (2003.08 - 2004.07)
Holden/H Series/VY | 5.7i V8/2003.08-2004.08/LS1 5665 Petrol 235 kW 320 BHP (2003.08 - 2004.08)
Holden/H Series/VZ | 5.7i V8/2004.08-2006.01/LS1 5665 Petrol 235 kW 320 BHP (2004.08 - 2006.01)
Holden/H Series/VY | 5.7i V8/2004.08-2006.02/LS1 5665 Petrol 235 kW 320 BHP (2004.08 - 2006.02)
Holden/H Series/VZ | 5.7i V8/2004.09-2005.12/LS1 5665 Petrol 235 kW 320 BHP (2004.09 - 2005.12)
Holden/H Series/5.7 i V8/2004.11-2005.12/LS1 5665 Petrol 235 kW 320 BHP (2004.11 - 2005.12)
Holden/H Series/VY | 5.7i V8/2002.09-2003.08/LS1 5665 Petrol 245 kW 333 BHP (2002.09 - 2003.08)
Holden/H Series/5.7 i V8/2003.08-2004.09/LS1 5665 Petrol 245 kW 333 BHP (2003.08 - 2004.09)
HSV/Senator/VT | 5.7i V8/1997.09-2000.08/LS1 5665 Petrol 250 kW 340 BHP (1997.09 - 2000.08)
HSV/Clubsport/VT | 5.7i V8/1999.07-2000.10/LS1 5665 Petrol 250 kW 340 BHP (1999.07 - 2000.10)
Holden/H Series/VZ | 5.7i V8/2004.09-2006.02/LS1 5665 Petrol 250 kW 340 BHP (2004.09 - 2006.02)
HSV/Clubsport/VX | 5.7i V8/2000.09-2002.09/LS1 5665 Petrol 255 kW 347 BHP (2000.09 - 2002.09)
HSV/Senator/VX | 5.7i V8/2000.09-2002.09/LS1 5665 Petrol 255 kW 347 BHP (2000.09 - 2002.09)
HSV/Maloo/VU | 5.7i V8/2001.03-2002.09/LS1 5665 Petrol 255 kW 347 BHP (2001.03 - 2002.09)
HSV/GTO/V2 | 5.7i V8/2001.03-2003.08/LS1 5665 Petrol 255 kW 347 BHP (2001.03 - 2003.08)
HSV/Clubsport/VY | 5.7i V8/2002.10-2003.08/LS1 5665 Petrol 260 kW 354 BHP (2002.10 - 2003.08)
HSV/Senator/VY | 5.7i V8/2002.10-2003.08/LS1 5665 Petrol 260 kW 354 BHP (2002.10 - 2003.08)
HSV/Maloo/VY | 5.7i V8/2002.10-2003.09/LS1 5665 Petrol 260 kW 354 BHP (2002.10 - 2003.09)
Holden/H Series/5.7 i V8/2004.09-2006.07/LS1 5665 Petrol 260 kW 354 BHP (2004.09 - 2006.07)
Vauxhall/Monaro/VY, VZ | 5.7/2004.03-2005.07/LS1 5665 Petrol 285 kW 387 BHP (2004.03 - 2005.07)
HSV/Clubsport/VY | 5.7i V8/2003.09-2004.09/LS1 5665 Petrol 285 kW 388 BHP (2003.09 - 2004.09)
HSV/GTO/VX, VZ | 5.7 i V8/2003.09-2004.09/LS1 5665 Petrol 285 kW 388 BHP (2003.09 - 2004.09)
HSV/Senator/VY | 5.7i V8/2003.09-2004.09/LS1 5665 Petrol 285 kW 388 BHP (2003.09 - 2004.09)
HSV/Maloo/VY | 5.7i V8/2003.10-2004.09/LS1 5665 Petrol 285 kW 388 BHP (2003.10 - 2004.09)
HSV/GTS/VT | 5.7i V8/2000.04-2000.09/LS1 5665 Petrol 300 kW 408 BHP (2000.04 - 2000.09)
HSV/GTS/VX | 5.7i V8/2000.09-2001.08/LS1 5665 Petrol 300 kW 408 BHP (2000.09 - 2001.08)
HSV/Senator/VX | 5.7i V8/2000.09-2002.09/LS1 5665 Petrol 300 kW 408 BHP (2000.09 - 2002.09)
HSV/GTS/V2| 5.7i V8/2001.03-2004.09/LS1 5665 Petrol 300 kW 408 BHP (2001.03 - 2004.09)
HSV/SV300/VX| 5.7i V8/2001.09-2001.12/LS1 5665 Petrol 300 kW 408 BHP (2001.09 - 2001.12)
HSV/GTS/VY | 5.7i V8/2002.10-2004.09/LS1 5665 Petrol 300 kW 408 BHP (2002.10 - 2004.09)
HSV/SV6000/6.0i V8/2005.08-2006.04/LS2(364CUV8) 5965 Petrol 297 kW 404 BHP (2005.08 - 2006.04)
Pontiac/Firebird/5.7/1992.11-1996.12/LT1(350CUV8) 5733 Petrol 205 kW 279 BHP (1992.11 - 1996.12)
Vauxhall/Monaro/VY, VZ | 5.7/2004.01-2004.10/Y 57 XE 5665 Petrol 245 kW 333 BHP (2004.01 - 2004.10)
Vauxhall/Monaro/VY, VZ | 5.7/2005.01-2007.04/Y 57 XE 5665 Petrol 257 kW 349 BHP (2005.01 - 2007.04) ,

Napiši mnenje

Napiši mnenje







  ali  Prekliči

Did not find your question?
Enter new question
Do you have a question? Search for an answer.




ZnamkaModelTypeKoda motorja
ChevroletCamaro5.7LS1 5665 Petrol 212 kW 288 BHP (1998.07 - 2002.12)
HSVClubsportVT 5.7i V8LS1 5665 Petrol 250 kW 340 BHP (1999.07 - 2000.10)
HSVClubsportVX 5.7i V8LS1 5665 Petrol 255 kW 347 BHP (2000.09 - 2002.09)
HSVClubsportVY 5.7i V8LS1 5665 Petrol 260 kW 354 BHP (2002.10 - 2003.08)
HSVClubsportVY 5.7i V8LS1 5665 Petrol 285 kW 388 BHP (2003.09 - 2004.09)
HSVClubsportVZ 6.0i V8L76, LS2(364CUV8) 5967 Petrol 297 kW 404 BHP (2004.10 - 2006.12)
HSVGTOV2 5.7i V8LS1 5665 Petrol 255 kW 347 BHP (2001.03 - 2003.08)
HSVGTOVX, VZ 5.7 i V8LS1 5665 Petrol 285 kW 388 BHP (2003.09 - 2004.09)
HSVGTOVX, VZ 6.0i V8L76, LS2(364CUV8) 5967 Petrol 297 kW 404 BHP (2004.10 - 2007.11)
HSVGTSV2| 5.7i V8LS1 5665 Petrol 300 kW 408 BHP (2001.03 - 2004.09)
HSVGTSVT 5.7i V8LS1 5665 Petrol 300 kW 408 BHP (2000.04 - 2000.09)
HSVGTSVX 5.7i V8LS1 5665 Petrol 300 kW 408 BHP (2000.09 - 2001.08)
HSVGTSVY 5.7i V8LS1 5665 Petrol 300 kW 408 BHP (2002.10 - 2004.09)
HSVMalooVU 5.7i V8LS1 5665 Petrol 255 kW 347 BHP (2001.03 - 2002.09)
HSVMalooVY 5.7i V8LS1 5665 Petrol 260 kW 354 BHP (2002.10 - 2003.09)
HSVMalooVY 5.7i V8LS1 5665 Petrol 285 kW 388 BHP (2003.10 - 2004.09)
HSVMalooVZ 6.0i V8L76, LS2(364CUV8) 5967 Petrol 297 kW 404 BHP (2004.10 - 2007.09)
HSVSV300VX| 5.7i V8LS1 5665 Petrol 300 kW 408 BHP (2001.09 - 2001.12)
HSVSV60006.0i V8LS2(364CUV8) 5965 Petrol 297 kW 404 BHP (2005.08 - 2006.04)
HSVSenatorVT 5.7i V8LS1 5665 Petrol 250 kW 340 BHP (1997.09 - 2000.08)
HSVSenatorVX 5.7i V8LS1 5665 Petrol 255 kW 347 BHP (2000.09 - 2002.09)
HSVSenatorVX 5.7i V8LS1 5665 Petrol 300 kW 408 BHP (2000.09 - 2002.09)
HSVSenatorVY 5.7i V8LS1 5665 Petrol 260 kW 354 BHP (2002.10 - 2003.08)
HSVSenatorVY 5.7i V8LS1 5665 Petrol 285 kW 388 BHP (2003.09 - 2004.09)
HSVSenatorVZ 6.0i V8L76, LS2(364CUV8) 5967 Petrol 297 kW 404 BHP (2004.10 - 2006.07)
HoldenH Series5.7 i V85665 Petrol 260 kW 354 BHP (2004.11 - 2005.12)
HoldenH Series5.7 i V8LS1 5665 Petrol 225 kW 306 BHP (2001.12 - 2003.01)
HoldenH Series5.7 i V8LS1 5665 Petrol 235 kW 320 BHP (2003.01 - 2003.08)
HoldenH Series5.7 i V8LS1 5665 Petrol 235 kW 320 BHP (2003.08 - 2004.07)
HoldenH Series5.7 i V8LS1 5665 Petrol 235 kW 320 BHP (2004.11 - 2005.12)
HoldenH Series5.7 i V8LS1 5665 Petrol 245 kW 333 BHP (2003.08 - 2004.09)
HoldenH Series5.7 i V8LS1 5665 Petrol 260 kW 354 BHP (2004.09 - 2006.07)
HoldenH SeriesVE 6.0i V8L76 5967 Petrol 260 kW 354 BHP (2007.09 - 2010.09)
HoldenH SeriesVT 5.7i V8LS1 5665 Petrol 220 kW 299 BHP (1999.06 - 2000.08)
HoldenH SeriesVT 5.7i V8LS1 5665 Petrol 220 kW 299 BHP (1999.06 - 2000.10)
HoldenH SeriesVU 5.7i V8LS1 5665 Petrol 225 kW 306 BHP (2000.12 - 2002.09)
HoldenH SeriesVX 5.7i V8LS1 5665 Petrol 225 kW 306 BHP (2000.09 - 2002.09)
HoldenH SeriesVY 5.7i V8LS1 5665 Petrol 225 kW 306 BHP (2002.09 - 2003.08)
HoldenH SeriesVY 5.7i V8LS1 5665 Petrol 225 kW 306 BHP (2003.09 - 2004.07)
HoldenH SeriesVY 5.7i V8LS1 5665 Petrol 235 kW 320 BHP (2002.09 - 2004.08)
HoldenH SeriesVY 5.7i V8LS1 5665 Petrol 235 kW 320 BHP (2003.08 - 2004.08)
HoldenH SeriesVY 5.7i V8LS1 5665 Petrol 235 kW 320 BHP (2004.08 - 2006.02)
HoldenH SeriesVY 5.7i V8LS1 5665 Petrol 245 kW 333 BHP (2002.09 - 2003.08)
HoldenH SeriesVZ 5.7i V8LS1 5665 Petrol 235 kW 320 BHP (2004.08 - 2006.01)
HoldenH SeriesVZ 5.7i V8LS1 5665 Petrol 235 kW 320 BHP (2004.09 - 2005.12)
HoldenH SeriesVZ 5.7i V8LS1 5665 Petrol 250 kW 340 BHP (2004.09 - 2006.02)
HoldenH SeriesVZ 6.0i V8 4x4L76, LS2(364CUV8) 5967 Petrol 260 kW 354 BHP (2005.11 - 2006.07)
HoldenH SeriesVZ 6.0i V8L76, LS2(364CUV8) 5967 Petrol 260 kW 354 BHP (2005.11 - 2007.08)
HoldenH SeriesVZ 6.0i V8L76 5967 Petrol 260 kW 354 BHP (2005.11 - 2006.06)
PontiacFirebird5.7LT1(350CUV8) 5733 Petrol 205 kW 279 BHP (1992.11 - 1996.12)
VauxhallMonaroVY, VZ 5.7LS1 5665 Petrol 285 kW 387 BHP (2004.03 - 2005.07)
VauxhallMonaroVY, VZ 5.7Y 57 XE 5665 Petrol 245 kW 333 BHP (2004.01 - 2004.10)
VauxhallMonaroVY, VZ 5.7Y 57 XE 5665 Petrol 257 kW 349 BHP (2005.01 - 2007.04)
